| CPU Socket
|
INTEL |
| |
1150/1151/1155/1156/1200/1366/2011/2011-3/2066/LGA 1700(GD240E) |
| |
AMD |
| |
AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2/AM5(GD240E) |
|
Water Block Dimension |
Φ65.5×49 mm |
|
Water Block Block Plate |
Copper |
|
Water Block Block |
Aluminum |
|
Radiator Dimension |
276 x 120 x 27 mm |
|
Radiator Material |
Aluminum |
|
Pump Speed |
4000±10% RPM |
|
Pump Rated Current |
0.34 A (0.45 A MAX) |
|
Pump Power Consumption |
4.08 W (5.4 W MAX) |
|
Pump Noise |
22 dBA |
|
Pump Flow |
850 ml/min |
|
Pump Operating Temperature |
-20℃~+60℃ |
|
Pump Storage Temperature |
-20℃~+70℃ |
|
Fan Dimension |
120 x 120 x 25 mm |
|
Fan Rated Voltage |
12 V |
|
Fan Control Method |
4-pin PWM |
|
Fan Power Consumption |
1.68-3.84 W (LED 3.12 W) |
|
Fan Speed |
600-2200 RPM |
|
Fan Noise |
14.3-35.6 dBA |
|
Fan Air Flow |
25.62-93.97 CFM |
|
Fan Air Pressure |
0.26-3.53 mm-H2O |
|
Tube Length |
400 mm |
| Accessories
|
1 to 3 ARGB Splitter Cable x1 |
