Description
| 24-pin ATX power | 1 |
| 4+4-pin CPU power | 2 |
| 6+2-pin PCIe power | 6 |
| SATA power | 6 |
| Peripherals | 6 |
| 24-pin ATX power | 600 mm, Nylon sleeving |
| 4+4-pin CPU power | 700 mm, Nylon sleeving |
| 6+2-pin PCIe power | 650 + 150 mm, Nylon sleeving |
| SATA power | 500 + 150 mm |
| Peripherals | 500 + 150 mm |
| 100 – 240Vac | 13A-6.5A 50Hz-60Hz |
| 3.3V and 5V | 22A (120W) |
| 12V | 83.5A (1002W) |
| 12V | 0.3A (3.6W) |
| 5Vsb | 3A (15W) |
| Total | 1000W |
| PF Correction | Active @0.96 |
| MTBF | 100,000 hours |
| Temperature | 0 – 50 °C (derating from 100% to 80% from 40 °C to 50 °C) |
| Rating | 80 Plus Gold |
| 20% loading | 87% @115Vac |
| 50% loading | 90.5% @115Vac |
| 100% loading | 87.5% @115Vac |
| Dimensions | 135 x 135 x 25 mm |
| Speed | 0-2300 ± 10% RPM |
| Airflow | 93.02 CFM (Tpy.) |
| Noise | 44.5 dBA max |
| Bearing | Fluid Dynamic Bearing (FDB) |
| Dimensions | 150 x 150 x 86 mm |
| Material(s) | Steel, PCB and Plastic |
