CPU Compatibility

Intel Socket LGA 1700, 1200, 115X, 2011*, 2066* – AMD Socket AM5, AM4, TR4*

Dimensions

120 x 288 x 52 mm

Cold Plate Dimensions

56 x 56 x 1.5 mm

Tube Length

400 mm

Total CPU Block + LCD Screen Height

105 mm

Fans

THICC FP12 x 2

120 x 120 x 32 mm

Fan Speed

0 – 3,000 RPM

Noise Level

<10.0* – 47.3 dBA – *Measuring below 10 dBA was not possible in our test chamber due to the noise floor

Maximum PSU Power Draw

Up to 180W depending on the number of connected Nexus Link devices

LCD Size

5 Inches

LCD Mounting Orientation

Portrait Only

LCD Resolution

720 x 1280 (293 PPI)

LCD Panel Type

IPS

LCD Refresh Rate

60 Hz

Pump RPM

2,000 – 4,500 RPM

Pump Impeller Diameter

24 mm

Coolant Operation Temperatures

-10 to 60 C

Input Connections

USB 2.0 Header

PWM

6-Pin PCIe Power

Included Accessories

Intel Mounting Kit

AMD Mounting Kit

 Fan Screws
