Output |
Max Configurable Power (Watts) |
450 Watts / 800VA |
|
Output Frequency (sync to mains) |
50/60 Hz +/- 1 Hz Unsynchronised |
|
Topology |
Line interactive |
|
Waveform type |
Stepped approximation to a sinewave |
Input |
Transfer Time |
6 ms typical : 10 ms maximum |
|
Input frequency |
50/60 Hz +/- 5 Hz Auto-sensing |
|
Number of Power Cords |
1 |
Batteries & Runtime |
Battery type |
Lead-acid battery |
|
Expected Battery Life (years) |
3 to 5 |
Communications & Management |
Control panel |
LED Status display with on line : on battery |
|
Audible Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge Protection and Filtering |
Surge energy rating |
156Joules |
Physical |
Maximum Height |
93MM, 9.25CM |
|
Maximum Width |
161MM, 16.05CM |
|
Maximum Depth |
305MM, 30.5CM |
|
Net Weight |
5.3KG |
Environmental |
Operating Temperature |
0 – 40 °C |
|
Operating Relative Humidity |
0 – 90 % |
|
Operating Elevation |
0 – 2032.1meters |
|
Storage Temperature |
-20 – 50 °C |
|
Storage Relative Humidity |
0 – 90 % |
|
Storage Elevation |
0 – 15240meters |
|
Audible noise at 1 meter from surface of unit |
40.0dBA |
